Complete harness set for left hand drive 911 T, E or S 1970 Coupe or Targa

The standard set includes the following items:

• Main harness from (front fusebox to dashboard) 911.612.002.00

• Front harness 911.612.003.00

• Headlight harness (2 x) 911.612.024.00

• Tunnel harness 911.612.001.00

• Rear light harness (2 x) 911.612.039.10

• Engine harness Motorola/Marchal/Sev 911.612.017.20
• CDI harness 911.612.050.00
• Battery cable to starter 901.611.031.21
• Battery connecting line 901.611.303.00
• Battery ground strap (with switchable clamp) 901.611.902.21
• Ground strap transmission 999.611.920.20
• License plate lights harness 901.612.041.21
• Trunk lights harness (double light) 901.612.042.00
• Instrument lights harness 901.612.043.03

• Also included, new pre-connected 2 x 8 pole fusebox with ceramic fuses and fuse list.

Depending on the version of your car you also need to add the following items to your shopping cart  see "related items")

• Interior lights harness Coupe 901.612.035.20 or Interior lights harness Targa 901.612.035.41

• Master brake cylinder harness 901.612.079.00 (only required for US models)

For single stage heater:

• Control harness (round relay) 911.612.054.00
• Window harness single 911.612.036.00

For two stage heater:

• Control harness (rectangular aluminum relay) 911.612.035.00
• Window harness two stage. 911.612.032.01

All further related items are optional (for example, AC, Power Windows, Ignition or light switch harness etc)

As original colored wiring.

Original neoprene terminal sleeves used, (no shrink tube!)

Very high quality flex automotive grade wiring, ISO6722:2002 / DIN72551/6 / EEC directive 2000/53
Gasoline, oil, battery acid, engine coolant resistant.
High flex sleeving ,very resistant to solvents and free of halogen, sulphur and phosphorous.
Handmade in Holland, concourse quality.

Required production time: 1 to 2 weeks

You can also ask for our free detailed quotation showing each harness ,further explanation and possible options.
